Manufacturer: Analog Devices Inc.
Product Category: Analog to Digital Converters - ADCs
Shipping Restrictions:
Mouser does not currently sell this product in your region.
RoHS: f compliant
Series: AD9268
Mounting Style: SMD/SMT
Package / Case: LFCSP-64
Resolution: 16 bit
Number of Channels: 2 Channel
Interface Type: Parallel
Sampling ratio: 125 MS/s
Input Type: Differential
Structure: Pipeline
Analog supply voltage: 1.8 V
Digital supply voltage: 1.8 V
SNR - Signal to Noise Ratio: 78.8 dB
Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C
Package: Tray
Trademark: Analog Devices
DNL - Differential Nonlinearity: - 1 LSB/1.2 LSB
Gain error: +/- 2.5 %FSR
Height: 0.83 mm
INL - Integral nonlinearity: +/- 5.5 LSB
Input voltage: 2 Vp-p
Length: 9 mm
Humidity sensitivity: Yes
Number of ADC inputs: 2 Input
Number of Converters: 2 Converter
Operating supply voltage: 1.8 V
Output Type: LVDS
Pd-Power Dissipation: 870 mW
Product Type: ADCs - Analog to Digital Converters
Reference type: External, Internal
Sample and Hold: Yes
Package Quantity: 260
Subcategory: Data Converter ICs
Supply Voltage - Max: 1.8 V
Supply Voltage - Min: 1.8 V
Type: S/H ADC
Width: 9 mm
Unit weight: 10 mg
