Manufacturer: Analog Devices Inc.
Product Type: Instrumentation Amplifiers
RoHS: yes
Series: AD623
Number of Channels: 1 Channel
3dB bandwidth: 800 kHz
SR - Conversion Rate: 300 mV/us
CMRR - Common Mode Rejection Ratio: 105 dB
Ib - Input bias current: 25 nA
Vos - Input bias voltage: 200 uV
Supply voltage - max: 12 V
Supply voltage - min: 2.7 V
Operating supply current: 375 uA, 305 uA
Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C
Mounting Style: SMD/SMT
Package / Case: SOIC-8
Package: Reel
Package: Cut Tape
Package: MouseReel
Amplifier Type: Instrumentation Amplifier
Trademark: Analog Devices
Dual supply voltage: 2.5 V to 6 V
Gain V/V: 1 V/V to 1000 V/V
Height: 1.5 mm (Max)
Length: 5 mm (Max)
Maximum input resistance: 2 GOhms
Operating supply voltage: 2.7 V to 12 V
Pd-Power dissipation: 650 mW
Product: Instrumentation Amplifiers
Product Type: Instrumentation Amplifiers
PSRR - Power Supply Rejection Ratio: 140 dB
Package Quantity: 1000
Subcategory: Amplifier ICs
Power Supply Type: Single, Dual
Vcm - Common Mode Voltage: 2.7 V to 12 V
Width: 4 mm (Max)
Unit weight: 540 mg
